Accessories - Torso Support

Print this page

Click to Enlarge

Item	Part/Kit	Part/Kit Description	Qty/Pkg	Qty/Asbly	MSRP	View Parts Notes
1	88804529X040	NLA - Pad, Headrest	1	1	N/A	B	Create/add to Wishlist Create/add to Wishlist New Wishlist Description
2	60284X001	Screw, Socket Head (1/4-20 x 1/2")	1	1	$10.00		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
3	88804529X043	NLA - Cover Torso Bracket	1	1	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
4	03018X043	Bracket, Clamp, Black- Right	1	1			Create/add to Wishlist Create/add to Wishlist New Wishlist Description
4	03018X046	Bracket, Clamp, Black - Left	1	1			Create/add to Wishlist Create/add to Wishlist New Wishlist Description
5	03018X041	NLA - Bracket, Pad Support, Chrome	1	1	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
6	11232X009	Bolt, Lug (5/16-24 x 1-3/8")	1	1	$10.00		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
7	7930363	NLA - Package, Locknut (5/16"-24)	25	1	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
8	03018X016	NLA - Bracket, Support, Chrome	1	1	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
9	7930360	NLA - Package, Screw, Phillips Pan Head (#10-32 x 11/16")	25	1	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
10	03018X012	NLA - Rod, Support w/ Guide Tube	1	1	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
11	8881050189	NLA - Torso Support Assembly (Pair)	1	1	N/A	B ,D	Create/add to Wishlist Create/add to Wishlist New Wishlist Description
11	8881050190	NLA - Torso Support Assembly (Pair)	1	1	N/A	B ,C	Create/add to Wishlist Create/add to Wishlist New Wishlist Description
	1023610	NLA - Instruction Sheet	1	1	N/A	A ,E	Create/add to Wishlist Create/add to Wishlist New Wishlist Description

Assembly Part Notes

Note Code	Definition
A	Not Shown
B	Specify upholstery color, see page titled "Packaging and Upholstery Colors".
C	Recliner
D	Non-Recliner
E	Item is no longer available from the Invacare Service Parts Department. Refer to the Invacare Website under "Product Literature Search". Enter the part number in the "Keywords" field and download a free PDF version copy.

Catalog Literature

Parts Books for Youthmobile 3000
