Cylinders - Locking Gas

Print this page

Locking Gas Cylinders

Click to Enlarge

Item

Part/Kit

Part/Kit Description

Qty/Pkg

Qty/Asbly

MSRP

View Parts Notes

1

60102821

Item	Part/Kit Description	Qty/Pkg	Qty/Asbly
2	Cylinder, Locking Gas	1	1
3	NLA - Screw, Socket Head w/ Patch (1/4-20 x 3/4")	1	4
4	Screw, Shoulder Hex Socket Head (5/16" x 2-1/2", 1/4-20)	1	2
5	Locknut (1/4-20)	1	2
2	Cylinder, Locking Gas	1	1
3	NLA - Screw, Socket Head w/ Patch (1/4-20 x 3/4")	1	4
4	Screw, Shoulder Hex Socket Head (5/16" x 2-1/2", 1/4-20)	1	2
5	Locknut (1/4-20)	1	2

Kit, Cylinder, Locking Gas w/ Mounting Hardware

1

1

$392.00

A

Create/add to Wishlist

Create/add to Wishlist

1

60104713

Item	Part/Kit Description	Qty/Pkg	Qty/Asbly
2	Cylinder, Locking Gas	1	1
3	NLA - Screw, Socket Head w/ Patch (1/4-20 x 3/4")	1	4
4	Screw, Shoulder Hex Socket Head (5/16" x 2-1/2", 1/4-20)	1	2
5	Locknut (1/4-20)	1	2
2	Cylinder, Locking Gas	1	1
3	NLA - Screw, Socket Head w/ Patch (1/4-20 x 3/4")	1	4
4	Screw, Shoulder Hex Socket Head (5/16" x 2-1/2", 1/4-20)	1	2
5	Locknut (1/4-20)	1	2

Kit, Cylinder, Locking Gas w/ Mounting Hardware

1

1

$392.00

B

Create/add to Wishlist

Create/add to Wishlist

Assembly Part Notes

Note Code	Definition
A	Includes items 2-5. Used for 300lb. Limit
B	Includes items 2-5. Used for 400lb. Limit

Catalog Literature

Parts Books for TDX®SP2 TDX®SP2-CG, TDX®SP2X-CG TDX®SP2-MCG, TDX®SP2X-MCG Power Wheelchair For Motion Concepts Ultra Low Maxx Rehab and Power Positioning System
