Wheels - Drive Wheels & Hardware (14" x 3") (TDX SI & TDX SI-2 Before 9/15/11) & TDX SI-HD
| Item | Part/Kit | Part/Kit Description | Qty/Pkg | Qty/Asbly | MSRP | View Parts Notes |
|---|
Assembly Part Notes
| Note Code | Definition |
|---|---|
| A | Includes items 2-4. |
| B | Includes items 6-10. |
| C | Not Shown. |
| D | Sold complete. Includes the Rims and (5) ea. Socket Head Screws w/ Patch (5/16-18 x 7/8"). Item #2 Rim w/ Hardware is used for Item #1 1144660 Drive Wheel only. |
| E | Part #1144660 is No Longer Available. Use part #1178834 as a replacement that is sold complete with Grey Tire/Black Rim, Metric Rim Hardware and Flat Free Gel Foam material. |
| E1 | It is recommended to order in pairs because of the flat free foam density difference. |
| F | 14" x 3" Tire w/ Soft Density Flat Free Gel foam (yellow) is not available for item #1 part number 1178834 and 1167685. Customer can use the Tire w/ Hard Density Flat Free foam (green) part #1141342. It is recommended to order in pairs to match. |
| G | For TDX SI-HD Before 6/4/12 and for TDX SI and TDX SI-2 |
| H | For TDX SI-HD After 6/3/12 (14" x 3") Wheel Assembly changed from Grey Tire/Black Rim to Grey Tire/Silver Rim and Flat Free Foam to Flat Free Gel Foam material. Sold complete. Item 2 is "not" used for Wheel Assembly part #1167685. |
